Mold Project: 20776-phasetwo-Tooling
Current Quote Currency Rate:  %
Start Metal Cut:  Status: Sample Sent
Start Date: 1/19/2024 Due Date:  On Hold Time: 0 days
Project Team: USA Project Engineer: Thalia Wang China Project Engineer: Tom Tang Supplier: Kailidi Precision Manufacture CO.,LTD
USA Accounting: Wendy Wang
Project Quotes: C-240113120939

Tooling Cost
ItemSnap ShotPart Number/NameMaterialSurface FinishColorCavitiesSample QuantityLead TimeCalculated Tooling PriceSuggested Tooling Price(RMB)UpDownDeleteFamily MoldUnfamilyUpdateReplace
1P2-2011830_REV02.stp
5RMB 15,917UpDownDeleteFamilyUnfamily
2P2-2019577_REV02.stp
5RMB 30,769UpDownDeleteFamilyUnfamily
3P2-2019579_REV02.stp
5RMB 29,448UpDownDeleteFamilyUnfamily
4P2-2026714_REV02.stp
5RMB 47,588UpDownDeleteFamilyUnfamily
5P2-2026721_MOD1.stp
5RMB 63,266UpDownDeleteFamilyUnfamily

Part Cost
ItemPart Number/NamePart SizePart WeightPart QuantityMaterial MOQ (Kg)Material CostProcess CostDHLRunner Weight(kg)Waste(kg)Injection Cycle(s)Machine Size(T)Volume FactorModifySecondary Process
1P2-2011830_REV02.stp77.4×75.9×5.1mm0.0137kg GoRMB 1.75RMB 2.99RMB 4.04
2P2-2019577_REV02.stp122.3×13.6×68.5mm0.0067kg GoRMB 1.75RMB 3.58RMB 5.47
3P2-2019579_REV02.stp122.3×18.9×69.6mm0.0258kg GoRMB 2.06RMB 3.98RMB 5.79
4P2-2026714_REV02.stp253.6×217.2×41.9mm0.1975kg GoRMB 13.42RMB 18.14RMB 35.49
5P2-2026721_MOD1.stp267.3×237.9×44.5mm0.3289kg GoRMB 15.35RMB 9.13RMB 37.65
Custom Process CostIBB-440-8 FLUSH TO 0.01 RECESS 4PC Setup Cost:
Lead Time: Days		Modify  Delete
